Fujitsu SPARC Enterprise M3000 Service Manual

Appendix E DC Power Supply Model E-3
FIGURE E-2 Rear View of the Server (DC Power Supply Model)
Location Number Component Maximum Number per Server
1 Power supply unit (PSU) 2
2PCIe slot 4
3RCI port
*
* For information on whether the RCI function is supported for your server, see the SPARC Enterprise
M3000/M4000/M5000/M8000/M9000 Servers Product Notes.
1
4 USB port (for XSCF) 1
5 Serial port (for XSCF) 1
6 LAN port (for XSCF) 2
7UPC port 2
8 Serial Attached SCSI (SAS) port 1
9 Gigabit Ethernet (GbE) port (for OS) 4
12
34
56 7
89
