Furuno FELCOM 15 Operator's Manual

2. SYSTEM INITIALIZATION
2-4
15. Press the [Enter] key to open the active port options window.
Setup
9. Configuration
System Setup
01:53 02-02-25 (YY-MM-DD)
INMARSAT-C
OFF
DTE1
DTE1
INT
ALL
System Date & Time
IMN
MES Operation Mode
Nav Port
Active Port
Message Output Port
EGC Output Port
Network Setup
Command Window
System setup menu, active port options window
16. Press the [↓] or [↑] key to choose active port (terminal unit); “INT” or “ALL” as
appropriate.
INT: Use main terminal unit.
ALL: Use the terminal unit (PC, etc.) connected to the DTE port on the main
terminal.
17. Press the [Enter] key to close the window.
18. Press the [↓] key to choose Message Output Port.
19. Press the [Enter] key to open the message output port options window.
Setup
9. Configuration
System Setup
01:53 02-02-25 (YY-MM-DD)
INMARSAT-C
INT
OFF
DTE1
System Date & Time
IMN
MES Operation Mode
Active Port
Nav Port
Message Output Port
EGC Output Port
Network Setup
Command Window
INT
EXT
INT+EXT
AUTO
System setup menu, message output port options window
20. Press the [↓] or [↑] key to choose the terminal unit where you want to route
received messages.
INT: All received messages are routed to the main terminal.
EXT: All received messages are routed to the terminal unit connected to
the DTE port on the main terminal unit.
INT+EXT: All received messages are routed to both the main and external
terminal units.
AUTO: The sub address for the DTE port is 001. Received messages
having the sub address of 001 are routed to the DTE terminal.
Messages having a sub address other than 001 are routed to the
main terminal.
21. Press the [Enter] key to close the window.
22. Press the [↓] key to choose EGC Output Port.
