5. MAINTENANCE, TROUBLESHOOTING
5-12
5.4 System Data
The system data display allows you to confirm the equipment and drive system status.
To show this display, open the [System Setup] menu, select [System Data] then push
the Course control knob. For details of the [System Setup] menu, see section 4.8.
To close the system data display, press the key.
Items on the system data display
[Input Voltage]: Voltage input to the NAVpilot.
[Controller ID]: ID of the controller that displays the system data
[Drive Type]: Drive type used with the NAVpilot. Not shown when [Boat Type] is set
to [EVCS Boat].
[Bypass/Clutch]: Presence or absence of bypass/clutch. Not shown with Fantum
Feedback
or when [Boat Type] is set to [EVCS Boat].
[P/C Temp]: Temperature of processor unit / control unit.
[Motor Drive Cur]: Motor drive current. Max. value is 25.0 A.
[Bypass/Clutch Cur]: Bypass/clutch current. Max. value is 3.0 A. Not shown with
Fantum Feedback
.
5.5 Messages
Your equipment displays messages to alert you to potential equipment problem and
operation status.
5.5.1 Message pop-up display
When the system detects alarm violation, error, etc., an error message and alarm icon
( ) appear and the alarm sounds. To stop the alarm and close the message, press
any key. If the error occurs frequently, contact your dealer.
Input Voltage: 24.4 V
Controller ID: 2
Drive Unit: Reversible 24V
Bypass/Clutch: Not Present
P/C Temp: 71.3
°
F/91.1
°
F
Motor Drive Cur: 10.0 A
Bypass Clutch Cur: 0.0 A
