4. USER MENU
4-10
4. Select the appropriate data to set the data source, then push the Course control
knob.
The following display example is when [Heading Sensor] is selected.
When [Auto Detect] is selected to [Yes], the NAVpilot automatically detects and
connects to data sources within the network. In case of multiple heading sensors,
the sensors are prioritized in the order of FURUNO CAN bus heading sensor, oth-
er CAN bus heading sensor, NMEA0183 heading sensor. After detecting sensors,
[Auto Detect] changes to [No] from [Yes]. If desired, you can change the data
source priority as follows:
1) Rotate the Course control knob to select the number then push the knob.
2) Rotate the Course control knob to select a sensor then push the knob.
5. Press the key several times to close the menu.
4.8 System Setup Menu
The [System Setup] menu provides various functions which once set do not require
frequent adjustment. Set the items in this menu according to operational needs, cur-
rent environment, etc. To open this menu, open the menu and select [Other Menu] fol-
lowed by [System Setup].
[System Setup] menu description
Item Description
[Key Beep] Turn the key beep on or off.
[ON]: The key beep sounds, [OFF]: No key beep
[Arrow Key] Set the function of arrow keys when pressed to dodge an obstruction in the
AUTO and WIND modes.
[Dodge], [5°], [10°], [Manual]. For [Manual], select degree of turn from 1°-90°.
[Turn Angle] Set the angle of User turn in the turn mode.
Setting range: 15°-360°, 15° steps
Heading Sensor
Auto Detect : No
1st: PG-700 : 0019E4
2nd: - - - - - - - - - - - - - -
3rd: - - - - - - - - - - - - - -
System Setup
Key Beep: OFF
Arrow Key: Dodge
Turn Angle: 15°
Key Lock: Unlock
Panel Dimmer: 8
To Next Page
