4. Press any key to show the rudder test result.
• [Drive Unit]: Drive type used with the NAVpilot: [Reversible 12V (or 24V)], [Safe-
Helm 12V (or 24V)], or [Solenoid].
• [Rudder Deadband]: Rudder Deadband ([OK] or [Big])
• [Rudder Speed]: Rudder speed ([OK], [Fast], or [Slow])
Note 1: If the rudder deadband is higher than 1.3°, the boat can not be controlled
correctly. Check for air in the steering system and if the rudder speed is greater
than 10°/s.
Note 2: Do not turn the power off within two seconds after finishing the rudder test.
If the power is turned off accidentally, retry the rudder test.
5. Press the key to close the rudder test window.
7.4.2 Dockside setup for Fantum Feedback
™
Drive unit setup
1. Select the current setting for [Drive Unit] from the [Dockside Setup] menu then
push the Course control knob.
2. Rotate the Course control knob to select the drive unit type then push the knob.
Setting option: [Reversible 24V], [Reversible 12V], [Safe-Helm 24V], [Safe-Helm
12V]
Push MENU key to Return
Drive Unit: Safe-Helm 12V
Rudder Deadband: OK
Rudder Speed: OK
Rudder Test
*: Displayed if Accu-Steer drive unit is selected.
Drive Unit: Safe-Helm 24V
Air Bleeding: No
Rudder Test: No
Helm Sensor Test*: No
Safe Helm/P.Assist Setup*
Dockside Setup
