Furuno NAVpilot-711C User Manual

5. MAINTENANCE, TROUBLESHOOTING
5-3
5.3.2 Processor unit test
This test checks the processor unit for correct operation. Open the diagnostic test op-
tions window, select [Processor Unit] then push the Course control knob.
To close the test result, press the key.
Test result items of the processor unit test
• [Processor Unit ID]: NMEA2000 Unique ID
• [ROM]: ROM test result ("OK" or “NG”), program number
• [RAM]: RAM test result ("OK" or “NG”)
• [Backup]: Backup data test result ("OK" or “NG”)
• [Rudder Angle]: The test result of rudder reference unit ("OK" or “NG”). For Fantum
Feedback
™
, "Fantum Feedback" is displayed. Not shown when [Boat Type] is set
to [EVCS Boat].
• [Bypass/Clutch]: Presence or absence of bypass/clutch and bypass/clutch amper-
age. "Not Present" shown in case of no connection. Not shown when [Boat Type] is
set to [EVCS Boat].
• [RC1/RC2]: Remote controller state (ON or OFF) and rudder signal input value. Not
shown with Fantum Feedback
™
.
• [INPUT VOLTAGE]: Source voltage
• [Port1/Port2/CAN]: I/O test for NMEA0183 and CAN bus ("OK" or “NG”).
• [CAN ID]: Control unit port ID
• [CPU/PWR]: CPU and PWR board version number
ROM: OK 6454007-**.**
6454009-**.**
RAM: OK Backup: OK
Rudder Angle: OK 0°
Bypass/Clutch: 0.7A
RC1/RC2: OFF -1° /OFF -2°
Input Voltage: 24.5 V
Port1/Port2/CAN: - -/- -/OK
CAN ID: 39713 CPU/PWR: */*
Processor Unit ID: 39768
*: Version no.
**.**: Program version no.
