6. INSTALLATION AND WIRING
6-2
6.1.2 When FAP-7011 is replaced with FAP-7011C
The width of FAP-7011 is different from that of FAP-7011C.
When FAP-7011 is installed on a desktop
The bracket used for FAP-7011 can not be used with FAP-7011C.
When FAP-7011 is installed with the surface mount
Do one of the following according to the thickness of the bulkhead (d):
• d
d 10 mm:
Using the mount template at the back of this manual, open a hole for the projection
of the control unit. Modification to the mounting hole (90 mm diameter) is not re-
quired.
10 mm < d
d 20 mm:
Using the mount template at the back of this manual, open a mounting hole of 95
mm diameter, and a hole for the projection of the control unit.
When FAP-7011 is installed with the flush mount
The square mounting hole for FAP-7011 is not compatible with FAP-7011C. Prepare
the mounting board for installing FAP-7011C.
