Furuno NAVpilot-711C User Manual

1. OPERATIONAL OVERVIEW
1-8
1.5.3 How to select the display data
You can select the display data to show in the STBY, AUTO, NAV, and WIND modes.
1. Long press the key to open the menu.
2. Rotate the Course control knob to select [Other Menu] then push the knob.
3. Rotate the Course control knob to select [System Setup] then push the knob.
4. Rotate the Course control knob to select [Display Data Select Menu] then push
the knob.
The window as shown below appears.
5. Rotate the Course control knob to select the steering mode desired then push
the knob.
6. Rotate the Course control knob to select the current setting for display division
desired then push the knob.
Note: Page layout of the page 3 depends on setting of [Data Box Format].
7. Rotate the Course control knob to select display data desired then push the
knob.
The table below shows all the display data available.
Page/Data Data Displayed Data meaning
Graphic / numerical data
Page 1: [Data 1]
Page 2: [Data 1]
Page 3: [Data 1]
[Normal] Numerical display (see section 1.5.2)
[Compass] Compass rose
[Highway] Graphic presentation of progress to-
wards waypoint
[Wind Apparent] Analog and digital apparent wind direc-
tion speed
[Wind True] Analog and digital true wind direction
speed
[Rudder]*
1
Analog and digital rudder angle
[Engine Speed] Analog engine speed (revolution meter)
Analog indicator
Page 1: [Data 2]
Page 2: [Data 2]
[Rudder]*
1
Rudder angle
[Deviation] Heading deviation
For WIND mode, wind deviation
[Steering Direc-
tion]*
2
Steering direction
*: Sailboats only
Display Data Select Menu
STBY
AUTO
NAV
WIND*
Data 1
Page 1
Data 1
Data 2 Data 2Data 3 Data 3
Data 1
Data 2
Page 2
Page 3
