7. INITIAL SETTINGS
7-5
7.4 Dockside Setup Menu
The [Dockside Setup] menu for the rudder reference unit (RRU) and Fantum Feed-
back
™
is different. To open the [Dockside Setup] menu, select [Dockside Setup] from
the [Installation Menu] window.
Note: The [Dockside Setup] menu is not shown when [Boat Type] is set to [EVCS
Boat].
7.4.1 Dockside setup for the rudder reference unit
RRU type
1. Select the current setting for [Select RRU Type] from the
[Dockside Setup] menu then push the Course control
knob.
2. Rotate the Course control knob to select a correct option then push the knob.
[Rotary(Inboard)]: For FURUNO rudder reference unit FAP-6112.
[Linear(Outboard)]: For Teleflex linear sensor AR4502.
RRU sensor alignment
1. Select [RRU Sensor Alignment] from the [Dockside Setup] menu then push the
Course control knob.
The message shown below appears.
Select RRU Type: Rotary (Inboard)
RRU Sensor Alignment
Air Bleeding: No
Rudder Limit Setup
Auto Rudder Limit:
Manual Rudder Limit:
Rudder Test: No
Dockside Setup
Rotary (Inboard)
Linear (Outboard)
Measure rudder center
position and confirm
displayed value is < 5°
if not, adjust RRU arm or
magnet. NAVPILOT will
correct reversed PORT
& STBD indication later.
Push any key to continue
