2. STEERING MODES
2-5
2.3.1 How to get the NAV mode
To get the NAV mode, do as follows:
1. Set the destination waypoint (or route) on the GPS navigator or chartplotter.
To navigate a route, make sure that your plotter is navigating towards the nearest
or required waypoint before you put the NAVpilot into the NAV mode.
2. Manually steer the boat toward the waypoint.
3. Press the NAV key.
You are asked if you are sure to navigate to the waypoint selected.
4. Push the Control course knob to start to navigate to the waypoint.
Note: The course reading on the NAVpilot is not always the same as the waypoint di-
rection shown on the chartplotter.
Display example: NAV mode
Direction to next waypoint
Waypoint name
Own ship mark
HDG THDG T
Set course or
XTE value
Estimated time of arrival
(Turn to STBD)(Turn to PORT)
Waypoint mark
Ship's heading
Analog indicator
or data box
Steering mode
㻦㻌[NAV Mode] = [Course]
㻦㻌[NAV Mode] = [XTE (Precision)]
㻦㻌[NAV Mode] = [XTE (Economy)]
