Furuno NAVpilot-711C User Manual

AP-1
APPX. 1 MENU TREE
Menu in STBY mode
Weather (Calm, 0°-10°, 1°; Moderate, 0°-10°, 2°; Rough, 0°-10°, 3°)
Rudder Gain (Calm, 1-20, 3; Moderate, 1-20, 5; Rough, 1-20, 10)
Counter Rudder (Calm, 0-20, 1; Moderate, 0-20, 2; Rough, 0-20, 4)
Long press the key in the STBY mode
Message
Display Color (White, Black)
Sensor In Use
Brilliance (1-8, 8)
Rudder Drive Level*
1
(1-20, the default is depended on the rudder test.)
Net Towing AUTO*
2
(OFF, ON)
Sea State (Full-Auto, Semi-Auto, Manual-Calm, Manual-Moderate, Manual-Rough)
Manual Paramer
Other Menu
Bold italic: Default
Alarm Buzzer (Internal, Internal+External)
Buzzer Interval (Short, Long, Continuous)
Watch Alarm (OFF, ON (1-99min, 5min))
Deviation Alarm (OFF, ON (1° to 90°, 30°))
XTE Alarm (OFF, ON (0.001-9.999NM, 0.054NM))
Wind Alarm*
3
Arrival Alarm (OFF, ON (0.01-9.99NM, 0.05NM))
Speed Alarm (OFF, Under, Over, Inside, Out of Range)
Under, Over: 0.0-999kn, 15.0kn,
Inside, Out of Range: 0.0-999.9kn, 15.0-20.0kn
Depth Alarm (OFF, Shallow, Deep, Inside, Out of Range)
Shallow, Deep: 0-999ft, 50ft,
Inside, Out of Range: 0-9999ft, 50-330ft
Temp Alarm (OFF, Under, Over, Inside, Out of Range, Shear)
Under, Over: 0°F-120F, 50°F,
Inside, Out of Range: 0°F-120F, 50°F-68°F,
Shear: 0°F-120F, 41°F
Trip Log (OFF, ON (0-9999NM, 100NM))
Clear Trip Log (No, Yes)
Heading Change Alarm
(OFF, ON (HDG, 0°-359°, 0°; Bnd, 1°-180°, 30°))
Wind Deviation Alarm (OFF, ON (1°-180°, 45°))
True Wind Spd Alarm (OFF, ON (0.1-99kn, 3.0-30.0kn))
App. Wind Spd Alarm (OFF, ON(0.1-99kn, 3.0-30.0kn))
(Continued on next page)
*
1
: Shown with Fantum Feedback
TM
.
*
2
: Not shown when [Boat Type] = [Sailboat] or in case of Fantum Feedback
TM
.
*
3
: Shown when [Boat Type] = [Sailboat].
