7. INITIAL SETTINGS
7-24
5. Press the key to return to the [CAN Bus Setup] menu.
6. Rotate the Course control knob to select [Select Output PGN List] then push the
knob.
This display shows all the NMEA 2000 PGNs that can be output to the connected
NMEA 2000 network. The sentences selected for output show “ON“. To turn a
sentence ON or OFF, go to step 7. If you do not need to change the settings, go
to step 8.
Note: Turn OFF the sentence “127245“ (rudder) in case of Fantum Feedback
™
.
7. To turn an NMEA 2000 sentence ON or OFF, do the following:
1) Rotate the Course control knob to select a sentence then push the knob.
2) Rotate the Course control knob to select [ON] or [OFF] then push the knob.
8. Press the key to return to the [CAN Bus Setup] menu.
9. Rotate the Course control knob to select the option for [Refresh] then push the
knob.
10. Rotate the Course control knob to select [Yes] then push the knob.
After five seconds, the [Devise List] display is refreshed.
CAN Bus
127237: ON
127250: OFF
127258: OFF
128267: OFF
126992: OFF
127245: OFF
127251: OFF
128259: OFF
*: The PGN title of the selected PGN is displayed.
System Time*
To Next Page
