Furuno NAVpilot-711C User Manual

7. INITIAL SETTINGS
7-36
3. For [Full-Auto], set the deviation level as follows:
1) Rotate the Course control knob to select the current setting for
[Deviation Level] then push the knob.
2) Rotate the Course control knob to select [Auto] or [Level].
For [LEVEL], you may set a value between 1 and 9. A lower number keeps
the course more precisely but the rudder may be turned more often. With a
higher number, the rudder is fixed, but the course may not be kept as precise-
ly.
How to manually set NAVpilot steering parameters
When [Manual-Calm], [Manual-Moderate] or [Manual-Rough] is selected as the sea
state, set [Manual parameter] as below.
You can set three parameters for the manual function: [Weather], [Rudder Gain] and
[Counter Rud.].
1. Rotate the Course control knob to select [Manual Parameter] from the [Parame-
ter Setup] menu then push the knob.
The display as shown below appears.
2. Rotate the Course control knob to select the current setting value of [Weather]-
[Calm] then push the knob.
3. Rotate the Course control knob to set a value (setting range: 0° to 10°) to push
the knob.
4. Set [Weather-Moderate], [Weather-Rough] similarly.
5. Set [Rudder Gain] and [Counter Rud.] similarly.
Setting range: 1-20 for [Rudder Gain], and 0-20 for [Counter Rud.]
Auto
Level
Manual Parameter
Weather
Rudder Gain
Counter Rud.
Calm Moderate Rough
1°2°
3
3°
1
5
2
10
4
