2. STEERING MODES
2-20
2.6.3 How to set FishHunter
™
turn parameters
You can set the parameters for the FishHunter
™
turns as follows:
1. Long press the key to open the menu.
2. Rotate the Course control knob to select [Other Menu] then push the knob.
3. Rotate the Course control knob to select [Fish Hunter Option] then push the
knob.
4. Rotate the Course control knob to select the turn desired then push the knob.
Set the parameters for each turn referring to the figure bellow.
Fish Hunter Option
Circle
Orbit
Spiral
Figure8
Square Turn
Circle
Rate of Turn: 3 °/s
Orbit
Radius: 0.05 NM
SPIRAL
Speed: 0.5 kn
Radius: 0.05 NM
Figure 8
Radius: 0.05 NM
Square Turn
Side Length: 1.0 NM
Azimuth: Auto
Zigzag
Turn Angle: 90 °
Termination: Continuous
Distance:
Number of Turns:
Width: 0.5 NM
Distance
Continuous
Number of Turns
Manual
Auto
Fish Hunter Option
Circle
Orbit
Spiral
Figure 8
Square Turn
Zigzag
<Setting range>
1°-5°/s
0.05-9.99 NM
[Speed]: 0.1-2.0 kn
[Radius]: 0.05-9.99 NM
0.05-9.99 NM
[Turn Angle]: 30°-150°
[Number of Turns]: 1-20
([Termination] = [Number of Turns])
[Distance]: 1-99 NM
([Termination] = [Distance])
[Width]: 0.1-9.9 NM
[Side Length]: 1.0-9.9 NM
[Azimuth]: 0-359° ([Manual])
