62
Figure 4-57 OSD info
Step 2 Configure OSD information. See Table 4-19.
Table 4-19 Description of OSD information
Select Enable, and the preset name is diaplayed in the image when the
camera turns to the preset, and it will disappear 3 s later.
Select Enable and the internal temperature of the current device is
displayed.
Select Enable and the PTZ coordinates info is diaplayed in the image.
Select Enable and the zoom info is displayed in the image. such as
, which means 12x zoom rate.
Select Enable and the north direction is displayed in the image.
Select Enable and it will enable RS-485 communication function.
Select Enable and set text, and the text is displayed in the image.
Alignment mode of the displayed information in the image.
Step 3 Move the OSD box to the position you want in the image.
Step 4 Click Save.
4.5.2.3.9 Configuring Counting
The image displays statistics of the enter number and leave number. When the overlay function
is enabled during intelligent rules configuration, this function is enabled simultaneously.
Step 1 Select Setting > Camera > Video > Overlay > Counting.
The Counting interface is displayed. See Figure 4-58.
