Gamatronic POWER PLUS - Figure 1-2: Sub-Assemblies; Figure 1-3: 10 Kva Configuration

Gamatronic Electronic Industries Ltd.
2 Power+ Technical Guide
The system comprises the following sub-assemblies.
1-10 UPS modules × 10kVA (4 in the example in Figure 1-2 below)
System Controller
Static Switch Module
Power Distribution Block
Figure 1-2: Sub-assemblies
Figure 1-3: 10kVA configuration
