Figure 4-2 below shows required switch and wire ratings for 10-100kVA installation.
For battery connections, see
Figure 6-3 on page 68.
Figure 4-2: Switch and wire ratings for 10-100kVA installation
POWER+ 400 V MODEL
UPS OUTPUT
CAPACITY (KVA)
S2 – S6
AND RA101
(AMPS)
WIRES
(mm
2
)
RA101
(OPTION)
(AMPS)
10 16 2.5 32
20 32 6 63
30 50 10 100
40 63 16 120
50 80 25 140
60 100 35 175
70 100 35 200
80 125 50 225
90 140 50 250
100 160 50 300
