Gamatronic Electronic Industries Ltd.
Power+ Technical Guide 101
14.4 PANEL AND SLAVE DIP SWITCH STATUS
Table 14-3: Panel and slave dip switch statuses
INFORMATION DESCRIPTION
DIP
Dual Inline Pin switch
ÇÈ
Position of the circuit breakers in the DIP switch
Ç = Circuit breaker is up
È = Circuit breaker is down
N-ID
New ID of rectifier
Norm
Battery test execution by command is normal
(internal rectifier command)
HiCap
High capacity battery set
F2
Number of active flash memory
R/W
Flash is upgradable (Read/Write)
chgbl
It is possible to switch the active Flash memory (Changeable)
noecH
No echo when the slave contacts the communication board
14.5 SC POWER+ INTERNAL POWER SUPPLY
Table 14-4: Controller external and internal power statuses
INFORMATION DESCRIPTION
MBRC
Exact value of the voltage of the 5V power supply
AUX
Power supplies in the controller
Good
The power supply is ok
Bad
A malfunction has occured in the power supply
14.6 SYSTEM TEMPERATURE
Table 14-5: System temperature displays
INFORMATION DESCRIPTION
Main Menu > System > press “down arrow” five times
Battery Temperature
Temperature reading from a sensor located near the batteries.
