Gamatronic Electronic Industries Ltd.
Power+ Technical Guide 85
11. SETUP PROCEDURES
The options in the Setup Menu enable you to configure system parameters.
Table 11-1: Setup Menu options
Option Description
1 ALARM SET
Opens menu with options for setting the threshold levels that
trigger alarms
2 UPS
Sets the UPS Parameters
3 BATTERY
Sets the Battery current parameters
4 CHARGE
Sets the Charge mode parameters
5 TIME
Sets the systems clock which sets a time stamp on log entries
6 SITE
Sets the power system's ID number
7 PASSWORD
Sets Level 1 Password
8 SERVICE
Opens menu of service utility programs
9 SILICON
Opens menu with options for restoring factory-defined default
values to parameters
11.1 SETTING ALARM THRESHOLDS
It is possible to define the threshold values for setting off alarms for the parameters of system
components. An alarm is set off each time a parameter value is outside the defined range of
permitted values.
Press the number that appears beside a menu option to open a screen in which you can set the
alarm thresholds for that option.
Table 11-2: Setting alarm thresholds
OPTION DESCRIPTION
0 AC VOLT
Sets the permitted AC voltage range (minimum and maximum input
voltage) and the AC voltage hysteresis
1 OUTPUT VOLT
Sets the permitted DC voltage range (minimum and maximum
output voltage)
6 BATTERY
Sets the permitted battery voltage range (minimum and maximum
output voltage) (indicates possible battery fault)
7 TEMPERATURE
Sets the permitted battery temperature range (minimum and
maximum temperature)
8 VIBRATION
Sets the number of times an alarm must occur within a specified
period of time to be considered a vibrating alarm
9 INTEGRATION
Sets the number of times the controller must receive an alarm from
the system before it logs the alarm
