Gamatronic POWER PLUS - Single UPS Module Specifications; Table 2-1 Single UPS Module Specifications

Gamatronic Electronic Industries Ltd.
Power+ Technical Guide 9
2.1.1 SINGLE UPS MODULE SPECIFICATIONS
Table
2-1 Single UPS Module Specifications
TECHNICAL DATA – UPS MODULE
Output Rated Power 10 kVA / 8 kW
Topology Online Battery, Double Conversion
Construction Modular parallel hot-plugged modules
Input Voltage (V) 3 × 400+N (3 × 230 V)
Input Voltage range (%) -27 and +20
Input Current (A) 15 A
Input Frequency (Hz) 47–63 Hz
Frequency tracking range (Hz) ±1, ±2, ±3 (selectable)
Output slew rate 1 Hz/sec
Power walk-in (sec) > 60
Input Power Factor 0.99
Input THDI (%) 5
Output Voltage (V) 3 × 400+N (3 × 230V)
Output Static Regulation (%) ±1
Output Regulation for unbalanced load (%) ±1 for 100% unbalanced load
Dynamic response to 100% load step (%) 2
110 % for 10 minutes
125 % for 60 seconds
Overload
1000 % for 1 cycle
Output Waveform Sinusoidal
Output THD (%) Less than 2 for linear load
Load CF (max) 6:1
Fuse clearance capability Input, Output, DC link
AC-AC efficiency (nominal) Up to 96 at full load
Maximum power dissipation (Po=8KW) 421 W (1437 BTU)
-10 to +40 (operating)
Ambient temperature (ºC)
-20 to +60 (storage)
Relative humidity (%) 95 max non-condensing
Altitude (m) 1500 w/o de-rating
DC-Link Voltage ±340 V to ±425 V
Cooling system Forced air: multi-fan with speed control
Dimensions: W x H x D 19" x 2U x 455 mm (Excluding shelf)
Weight 9.5 Kg
