Gamatronic Electronic Industries Ltd.
Power+ Technical Guide 77
Table
9-1: UPS Module Indicators
CONDITION LINE
(GREEN)
OUTPUT
(GREEN)
ALARM
(RED)
BEEPS REMARKS
Wake-up
On On On
Start
Off Off Off About 1 minute
Normal
Operation
On On Off
Abnormal
Input voltage
Off On On
One phase
abnormal input
Blinks On Off
High Input
Current
Blinks On On
Vdc > 450V
On Off Off High Vdc
Vdc > 500V
On Off On Very high Vdc
DC imbalance
On On Blinks
Low Vdc< 360V
On* On Blinks
Vdc very low,
< 320V
On* Off On
DC critical fail
< 200V
Blinks Off On
* Mostly will be
caused by Vin
fault that will turn
off LINE LED
Circulation
Current
On Off On
Output overload
On Blinks Off
Output is
disconnected
On Blinks On Result of output
overload
Communication
failed
On On On Or absence of
System
Controller
Output
short-circuit
Blinks Off On
