Gamatronic Electronic Industries Ltd.
Power+ Technical Guide 75
Battery Checks
Turn the battery circuit breaker to Off and disconnect all Anderson connectors in the battery set.
Record the battery serial number, type, and number of cells in the table below:
Battery
manufacturer
Battery model Rating (Ah) Number of strings (x 32)
Use a power resistor of 0.5
Ω (300 W rating recommended) for the load to check the voltage drop across the
terminals of each battery. There should be no more than a 10 Vdc drop for any battery.
Replace any batteries that seem to be inadequate.
BATTERY STRING #1 BATTERY STRING #2
Batt.
no.
Good Bad
Batt.
no.
Good Bad
Batt.
no.
Good Bad
Batt.
no.
Good Bad
1 17 33 49
2 18 34 50
3 19 35 51
4 20 36 52
5 21 37 53
6 22 38 54
7 23 39 55
8 24 40 56
9 25 41 57
10 26 42 58
11 27 43 59
12 28 44 60
13 29 45 61
14 30 46 62
15 31 47 63
16 32 48 64
END OF MAINTENANCE PROCEDURES REPORT
