GPSMAP
®
700 Series Owner’s Manual 73
Radar
5. Touch a data eld.
6. Select a category of data.
7. Select the data that will be displayed.
Conguring the Navigation Inset on the Radar Screen
The navigation inset is shown only when the boat is navigating to a destination.
1. From the Home screen, select
Radar.
2. Select
Cruising, Harbor, Offshore, or Sentry mode.
3. Select
Menu > Radar Setup > Overlay Numbers.
4. Select
or to select a data overlay.
5. Select
Navigation Inset.
6. Select
Nav. Inset Cong.
7. Complete an action:
Select Route Leg Details > On to show waypoint velocity made good (VMG) when
navigating a route with more than one leg.
Select Next Turn > Distance to show next-turn data based on distance.
Select Next Turn > Time to show next-turn data based on time.
Select Destination, and select Distance, Time to Destination, or Arrival to indicate how the
destination data appears.
Showing the Compass Tape on the Radar Screen
The compass tape appears in a row across the top of the radar screen. It shows the current heading,
and an indicator that shows the bearing to the desired course appears while navigating.
1. From the Home screen, select
Radar.
2. Select
Cruising, Harbor, Offshore, or Sentry mode.
3. Select
Menu > Radar Setup > Overlay Numbers.
4. Select
Show Compass Tape.
Radar Display Settings
Setting the Radar Color Scheme
You can set the color scheme used for all Radar screens.
1. From the Home screen, select
Radar > Radar Setup > Appearance > Color Scheme.
2. Select
White, Black, or Blue.
Setting the Radar Display Orientation
You can set the perspective of the radar display. The orientation setting applies to every radar mode.
1. From the Home screen, select
Radar > Radar Setup > Orientation.
2. Complete an action:
Select North Up to set the top of the radar to a north heading.
Select Head Up to set the top of the radar according to the heading data received from a
heading sensor, also known as the magnetic heading. The heading line appears vertically on
the screen.
Select Course Up to set the radar so the direction of navigation is always up.
•
•
•
•
•
•
•
