GERAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
3-32 Section 3-8 - Printer Installation
Section 3-8
Printer Installation
NOTE: For Connection schemes refer to Section 3-6 "Connection of Auxiliary Devices" on page 3-11.
For further installation instructions see:
• Section 3-8-1 "Installing Digital Black & White Printer Sony UP-D898" on page 3-32
• Section 3-8-2 "Installing Digital Color Printer Sony UP-D25MD" on page 3-27
• Section 3-8-5 "Adjustment of Printer Settings" on page 3-37
3-8-1 Installing Digital Black & White Printer Sony UP-D898
1) Power off/Shutdown the system as described in: Section 3-7-3 on page 3-25.
2) Physically connect the printer cables as described on Section 3-6-2 on page 3-13.
!! NOTICE:
After boot up of the system, verify the correct settings in the printer “Properties”,
see: Section 3-8-4 "Adding Printer to the system" for assigning the Printer to the remote keys P1
, P2,
P3
, P4, P5 and/or P6, and
see: Section 3-8-5 "Adjustment of Printer Settings" .
