GEDRAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
Chapter 4 - Functional Checks 4-9
4-3-2-2 LCD ARM
1) Loosen LCD Arm LOCK (see: Figure 4-5)
.
Figure 4-6 LCD ARM Lock
2) Verify LCD Monitor can move up/down (vertically) and left/right (horizontally).
NOTE: LCD Monitor can move approximately 150mm vertically and 250mm horizontally (see: Figure 4-6).
Figure 4-7 LCD Movement
• a, b : LOGIQ P7/P9 with Flexible Arm
• c : LOGIQ P7/P9 with Fixed Arm
3) Engage LCD Arm LOCK.
4) Align LCD Arm along center line of the system.
5) Verify LCD Panel is locked to position and LCD ARM does not move.
a
b
c
