GE LOGIQ P7 Service Manual

GEDRAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
Chapter 3 - Setup Instructions 3-39
3-8-5-2 UP-D25MD - Printer Settings
1) Call up the ‘Printer Preferences’; operation see: Section 3-8-5 "Adjustment of Printer Settings" .
2) Select the
PAPER page and select:
- Recommended Paper: UPC-24LA (large) / UPC-24SA (small)
NOTE: Paper UPC-21L and UPC-21S are also acceptable paper to use.
- Orientation: Landscape (recommended when using large paper size)
- High Speed (check mark on)
3) Select the
GRAPHICS page. From the “Color Adjust” pop-up menu select:
a) Color Balance: Cyan = 0; Magenta = 0; Yellow = 0
NOTICE
!! NOTICE:
Settings for Paper Size MUST match with the used Paper (large/small) and also the right color ink
cartridge has to be used. Otherwise you will get an error message at printing.
Figure 3-26 Paper page
