Chapter 10 - Care & Maintenance 10-5
Section 10-4
Tools Required
10-4-1 Special Tools, Supplies and Equipment
10-4-1-1 Specific Requirements for Care & Maintenance
Table 10-3 Overview of Requirements for Care & Maintenance
Tool Part Number Comments
Digital Volt Meter (DVM)
minimum 5% accuracy, 3.5 digit and 200 Ohm range required
Anti Static Kit
46–194427P231
46–194427P279
46–194427P369
46–194427P373
46–194427P370
Kit includes anti–static mat, wrist strap and cables for 200 to 240
V system
3M #2204 Large adjustable wrist strap
3M #2214 Small adjustable wrist strap
3M #3051 conductive ground cord
Anti Static Vacuum Cleaner
46–194427P278
46–194427P279
120V
230V
Safety Analyzer 46–285652G1
DALE 600 KIT (or equivalent) for electrical tests
QIQ Phantom E8370RB
RMI Grayscale Target Model 403GS
CD-RW Media
(minimum quad speed)
DVD+RW Disc Media blank H48641D
blank 4,7GB DVD+RW disc
B/W Printer Cleaning Sheet
see printer user manual for requirements
Color Printer Cleaning Sheet
see printer user manual for requirements
Disposable Gloves
Screwdriver PH0
Screwdriver PH1
Screwdriver PH2
