8-68 Section 8-8 - Replacement of Side Cover

8-8-3-2 Removal Procedure - Side Cover (R)

1) Remove Top Cover.

2) Remove knobs

Figure 8-52 Removing RS probe knobs

Figure 8-51 Removal of Top cover
