GERAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

5-10 Section 5-2 - General Information

5-2-4-4 S-Video / Composite

There are S-video / Composite port for external display

<S-Video 4Pin Mini-DIN Female>

Table 5-7 S-Video 4Pin Mini-DIN Female

Pin number Signal name

1 GND / Ground (Y)

2 GND / Ground (C)

3 Y / Intensity (Luminance)-

4 C / Color (Chrominance)

Pin number Signal name

1 1 plus screen
