GE
RAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019)
S
ERVICE
M
ANUAL
8-166
Section 8-39 - Replacement of
Bottom Fan Filter
Section 8-39
Replacement of Bott
om Fan Filter
8-39-1
Manpower
1 Person, 3 minutes.
8-39-2
Tools
None Requ
ired.
8-39-3
Removal Procedure
1)
Pull out bottom fan filt
er as following figure.
Figure 8-197 Removal of bottom fa
n filter
8-39-4
Installation Procedu
re
In Reverse Order.
8-39-5
Functional Check
Visual inspection Only.
491
493
