3-56 Section 3-12 - Connectivity Setup
3-12-1-3 Stand-alone LOGIQ P9/P7
If digital images or 3D/4D data sets (if available) are stored, they should be saved in the Archive (Image
Management System software).
For Image Management functionality refer to the Basic User Manual of the LOGIQ P9/P7.
Physical Connection:
No network connection needed.
3-12-1-4 LOGIQ? + PC within a “Sneaker Net”
A PC is used for review and work on studies acquired on one or more LOGIQ P9/P7 scanners without
being connected in a network.
The images are first stored on the LOGIQ P9/P7 scanner’s hard drive (Archive) and then exported from
the scanner’s hard drive to a sneaker device (e.g., DVD/CD), and finally imported from the sneaker
device to the PC’s internal hard drive.
For Image Management functionality refer to the Basic User Manual of the LOGIQ P9/P7.
Physical Connection:
No network connection needed.
3-12-1-5 Connection between LOGIQ? and DICOM Server
In this configuration, the LOGIQ P9/P7 is configured to work with a DICOM server in a network
environment. Usually, this will be the hospital network. Images are first saved on the local image buffer
on the scanner. At the end of the examination, the images are sent to the DICOM server via a DICOM
spooler. This scenario requires that the scanner is configured to be connected to the DICOM server.
Physical Connection:
You will need one network cable.
1) Connect one end of the cable to the Ethernet connector on the LOGIQ P9/P7.
2) Connect the other end of the cable to the wall outlet.
NOTE: If a Peer-to-Peer Network is connected to the hospital’s network, you may connect the LOGIQ
P9/P7 to the Peer-to-Peer Network.
For more details refer to Section 3-13 "Configuring Connectivity" on page 3-58.
NOTICE
!! NOTICE:
To avoid loss of essential data, it is highly recommended to export/backup patient data as well as
measurements at least once a month.
