Chapter 3 - Setup Instructions 3-45
Table 3-16 Monitor (R1.x.x)
Table 3-17 Power Assistant (R2.x.x)
Table 3-15 Scan Assistant
Preset Parameter Description
Auto Selection Off, Category, or Description.
• Off. The Scan Assistant selection on the Patient screen is completely manual. It will say
“None” when starting a new patient and you can make a selection manually if desired.
• Category. Scan Assistant uses the combination of exam category (Abd, OB, etc.) and the
currently-selected user to automatically select a Scan Assistant program. It chooses the
same program that was used the last time this combination of exam category and user.
The user can manually override this auto selection.
• Description. Scan Assistant uses the combination of the exam description (often auto fills
in if the patient was selected from the worklist) and the currently selected user to
automatically select a Scan Assistant program. It will choose the same program that was
used the last time this combination of exam description and user was selected. The user
can manually override this auto selection. If the exam description is blank then it will do
the auto selection based on Category as described in the previous paragraph.
Always Use Doppler Cursor Use the Doppler Cursor when you activate Scan Assistant.
Preset Parameter Description
Dark Pre-defined monitor settings for Dark Room
Semi Dark Pre-defined monitor settings for Semi-Dark Room
Light Pre-defined monitor settings for Light Room
OSD Control The monitor can also be adjusted in brightness and contrast. For detailed adjustment press
the [ OSD controls] buttons on the screen. The OSD menu will appear on the screen.
Brightness, Contrast, Backlight and Sharpness can be adjusted in General tab. Monitor
colors can be adjusted in RGB tab.
Preset Parameter Description
Allow offline scanning (restarted
needed)
Allow users to scan without AC power if battery option is installed. User need to reboot the
system to activate offline scanning.
Battery Low Warning with Sound Make beep sound when the installed battery is running out.
