GERAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

8-102 Section 8-17 - Replacement around Nest Box

3) Remove 5 screws and Cable Cover Bracket.

Figure 8-107 Cable Cover Bracket

4) Disconnect Cables.

Figure 8-108 Cable Disconnecting points

Cable Cover

Bracket
