8-106 Section 8-17 - Replacement around Nest Box

3) Draw MPI, MCB and IO Box out of the Nest Frame.

Figure 8-114 Separating Board Assy

Figure 8-115 Board assys in Nest Box

MDC board assy

IO BOX assy

MPI board assy

MCB board assy
