Chapter 8 - Replacement Procedures 8-151

4) Disconnect 2 BW printer cables from the rear panel. Refer to following figure.

Figure 8-177 BW printer connectors

5) Disconnect 2 BW printer cables from printer and carefully pull out the cables.

Figure 8-178 Removal of printer cables from the printer

USB signal connector

AC Power connector
