Chapter 8 - Replacement Procedures 8-181
3) Unscrew 7 screws to remove the NEST EMI BRKT and pull out MIO ASSY from system.
4) Unscrew 12 screws to remove the MIO BOX BRKT.
Figure 8-218 Unscrewing 7 screws to remove NEST EMI BRKT and MIO ASSY
Figure 8-219 Unscrewing 12 screws to remove MIO BOX BRKT
