GE
DRAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019
)
S
ERVICE
M
ANUAL
Chapter 8 -
Replacement Pr
ocedures
8-187
7)
Disconnect PWR and SIG connectors.
8)
Disassemble BATTERY ASSY.
9)
Disassemble MBOB PWR HARNESS (572831
7) and MBOB SIG
HARNESS (5728318)
Figure 8-231
Disconnecting PWR and SIG c
onnectors
Figure 8-232
Disassembling BA
TTER
Y
ASSY
Figure 8-233 Disass
embling MBOB PWR HARNESS (5728317)
and MBOB SIG HARNESS (5728318)
512
