GE
DRAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019
)
S
ERVICE
M
ANUAL
Chapter 8 -
Replacement Pr
ocedures
8-193
3)
Disassemble
CONNECTOR BRKT using
2 screws. (2327596, SCREW WH M3X6)
4)
Disconnect BATTERY SI
G HARNESS
and PWR HARNESS.
NOTE:
Both connectors are locking type. Please
pull out connectors pressing locking
points.
Figure 8-241 Disassembling CONNECT
OR BRKT using 2 screws
Figure 8-242 Disconnecting BA
TT
ERY
SIG HARNESS and PWR H
ARNESS
518
520
