GE
RAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019)
S
ERVICE
M
ANUAL
8-196
S
ection 8-49 - Replaceme
nt of BBC
7)
Unscrew 8 screws to remove
BATTERY PACK TOP BRKT.
8)
Remove 4 BATTERY PACK
S.
Figure 8-245 Unscrewing 8 screws to remov
e BA
TTER
Y
P
ACK TOP
BRKT
Figure 8-246 Removing 4 BA
TTER
Y P
ACKS
BATTERY PACK
TOP BRKT
521
523
