GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 9 - Renewal Parts 9-23

512

Fixed Arm Cover sets

5582893 Plastic Cover 1 1 Y Y Y N

513

Fixed Arm Cover Set

S5794075 Plastic Cover 1 1 N N N Y

514

AC Cable Holder set

5589119

Power Cord Fix BRKT 220V, Power Cord Fix

BRKT 110V

11YYYN

515

Gel Holder R2

5508055-2 Gel holder 1 1 Y Y Y N

516

Gel Holder R3

5794072 Gel holder 1 1 N N N Y

517

Link Arm Cable Hook

5507026 Link Arm Cable Hook 1 1 Y Y Y N

518

Link Arm Cable Hook

5794895 Link Arm Cable Hook 1 1 N N N Y

519

Option Tag Label

5573772 Option Tag Label 1 1 Y Y Y N

520

Option Tag Label R3

5794163 Option Tag Label 1 1 N N N Y

521

LOGIQ P9 ROTATION

MODULE KIT

5728965 LOGIQ P9 ROTATION MODULE KIT 1 1 Y Y Y N

522

RS KNOB SET R3

S5794028 RS KNOB SET R3 1 1 N N N Y

Table 9-10 Mechanical Parts

Ite

Part Name Part Number Description Qty FRU R1 R2 R2.5 R3
