GEDRAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
Chapter 9 - Renewal Parts 9-27
Table 9-11 Options
Item Part Name
Part
Number Description Qty FRU R1 R2 R2.5 R3
701
Multi Purpose Holder set
5582894 Multi Purpose Holder and Gel Cup 1 1 Y Y Y N
702
USB Footswitch, 3 button
5380960-2 3 button switchs operated by the feet 1 1 Y Y Y N
703
LCD Arm
5538531 Full assy for LCD Monitor 1 1 Y Y Y N
704
LCD Arm R3
5794197 Full assy for LCD Monitor 1 1 N N N Y
705
LCD Arm Plastic Covers
5548571 Plastics 1 1 Y Y Y N
706
LCD Arm Plastic Covers 3
S5794170 Plastics 1 1 N N N Y
707
OPIO Tray set
5603831 OPIO Tray, Tray Fix BRKT 1 1 Y Y Y N
708
Paper Tray
5499671 Plastics 1 1 Y Y Y N
709
Side Tray Assy
5582897 Side Tray L, R 1 1 Y Y Y N
710
Drawer Assy
5537774 Drawer Assy 1 1 Y Y Y N
711
Drawer Assy R3
5794898 Drawer Assy 1 1 N N N Y
712
Rear Handle
5730809 Rear Handle 1 1 Y Y Y N
713
Rear Handle R3
5794081 Rear Handle 1 1 N N N Y
714
Probe cable hanger
5172249 Probe cable hanger 1 1 Y Y Y N
715
Rear Cable Hook
5394433 Rear Cable Hook 1 1 Y Y Y N
716
OPIO Side Rear Hook R3
5730661 Rear Cable Hook 1 1 N N N Y
717
Card Reader BRKT set
5599965
Card Reader BRKT, Self adhesive hook
and loop
1 1 Y Y Y N
718
MCWD assy
5717876 MCWD assy 1 1 Y Y Y N
719
ECG
5570914 ECG 1 1 Y Y Y N
720
Gel Warmer
5537501-2 Gel warmer 2 LP7P9 1 1 Y Y Y N
721
Gel Warmer Cap
5491354 Bottom of Gel Warmer 1 1 Y Y Y N
722
Gel Warmer 2 LP7P9 R3
5794080 Gel Warmer 1 1 N N N Y
723
Gel Warmer Cap LS8 R3
5692045 Bottom of Gel Warmer 1 1 N N N Y
724
Multi Purpose Holder Set R3
S5794159 Multi Purpose Holder and Gel Cup 1 1 N N N Y
725
ECG Assy
5599525 LOGIQ P7_P9 ECG Module Assy 1 1 Y Y Y N
726
MARU WIRELESS LAN
ASSY for Japan
MARU WIRELESS LAN
ASSY except for Japan
5599724
5599725
MARU WIRELESS LAN ASSY for Japan
MARU WIRELESS LAN ASSY except for
Japan
1 1 Y Y Y N
727
BT820-02 Laird Bluetooth
dongle R3 only
5799898 BT820-02 Laird Bluetooth dongle R3 only 1 1 N N N Y
