GERAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
3-6 Section 3-3 - Receiving and Unpacking the Equipment
Section 3-3 Receiving and Unpacking the Equipment (cont?)
Figure 3-4 envelope at front panel of the crate
Table 3-5 Unpacking Procedure
Step Task
1.
Remove the top cover, then remove the out sleeve.
2.
Remove the option box on front of the system.
Check whether delivery is complete
(according to packing list) and check visual damage!
The envelope with delivery address, packing list and
invoice is located on the front panel of the crate.
Option box on front of the system
