24 0000010291
001
2.3 Specifications
Standard ma-
chine
Form plate di-
mensions
Ambient condi-
tions
Type plate The (standard) GEA type plate is located on the back of the machine. The type
plate contains information about the items, listed below:
Item Specifications
Machine dimensions
(width x depth x height) in mm
1240 x 3300x 2700
Weight in kg 1800
Material Stainless steel
Noise emission 83 dB(A)
Water pressure 4 bar max.
Compressed air pressure 6 bar
Compressed air consumption 300 litres/minute
Hydraulic tank capacity 160 litres
Item Specification
Form plate width 600 mm
Form plate height 6 - 40 mm
Item Condition
Temperature with air cooling 5 °C < T < 25 °C
Temperature with water cooling 5 °C < T < 40 °C
Relative humidity < 95 %
Item
Type Machine serial number
Year Supply voltage [V]
(number of) Phase Frequency [Hz]
Power [kW] Full-load current [A]
