3.2 Installation
General
1. Place the machine on a flat and level sur-
face. For dimensions (A), (B) and (C) refer to
section 2.3 "Specifications".
2. Remove all the transport packaging.
3. Level the machine.
Platform
1. Place the platform (A) on the machine.
2. Attach the hose for the foot button (D) to the
connection on the machine (C).
3. Attach the steps (B).
Electricity 1. Connect the 3-phases to the connection block within the electrical cabinet.
2. Earth the machine according to the local regulations.
3. Change the polarity of two phases if the phase order is wrong.
Connections
1. Connect the compressed air facility (B).
2. Connect the water supply (A). Use a hose
clamp.
3. If desired, connect a water outlet hose to the
collection tank. Use a hose clamp.
Password GEA
control
The GEA control includes different levels to prevent unauthorized access.
C
B
A
D
A
B
C
B
A
Level Description Default
0 Operator -
1 Cleaning 147
