30 0000010291
001
Screen 1022
Screen 1003
Screen 1004
Screen 1005
Item Description
Form plate > stroke:
length [mm]
The stroke length of the form plate needs to be filled.
Form plate > position
(press blocks: up) [mm]
The position of the form plate (outwards stroke)
where the press block is raised.
Form plate > speed [m /
min]
The calculated speed of the form plate.
Item Description
Knockout > time [s] The duration of the stroke of the knockout to the low-
est position. (0 - 0.2 seconds)
Air blast > offset [s] The timing of the air blast of the knockout in relation
to the lowest position of the knockout. (-0.05 - 0.05
seconds)
Knockout > heating To activate the knockout heating.
Item Description
Filling [s] The time the form plate stops to be filled. (0 - 0.5 sec-
onds)
Press block > delay
time [s]
The time the stroke of the press block is delayed after
the start of the inward stroke of the form plate. (0 - 0.2
seconds)
Step filling To activate step filling. This setting divides the stroke
of the press block into several steps over several
strokes of the form plate before the press block is
raised.
Press block > pressure
build up: delay time [s]
When step filling is activated, this value replaces the
Press block> delay time when the press block is not
raised. (0 - 0.3 seconds)
Item Description
Nozzle (front side) > de-
lay time [s]
The delay time before the nozzle starts to spray after
the start of the inward stroke of the form plate. (0 - 3
seconds)
Nozzle (front side) [s] The time the nozzle sprays water. (0 - 1 seconds)
Nozzle (back side) [s] The time the nozzle sprays water. The nozzle starts
to spray at the start of the inward stroke of the form
plate. (0 - 1 seconds)
