5 Settings
5.1 General Settings
1. Select Setting from the Main Menu.
2. Select General from the Setting menu.
3. Press the PAGE key to scroll through the screens of available settings.
Example: Screen 1/4
Reset To reset settings to the default values.
OK To save changes and return to previous
screen.
To toggle through the available screens press the
PAGE key.
Screen 1/4
Field Description
Light Off, Low,
Medium, High
Sets the level of screen illumination.
Contrast 1 (low) to 9
(high)
Sets the display contrast in steps from 1 to 9.
Trigger Key Off MEAS key is disabled.
ALL Functionality of MEAS key is set to "Measure distance
and save".
DIST Functionality of MEAS key is set to "Measure distance".
User Key1/User
Key2
Level, Offset,
NP/P, HT.
Transfer, Hid-
den Point,
Free Coding,
Laser, Light,
Unit Setting,
Main Setting,
EDM Tracking
Assigns the selected functionality of the function menu
to the key
Key Beep The beep is an acoustic signal after each key stroke.
On Beep is enabled.
Off Beep is disabled.
Sector Beep On Beep sounds at right angles (0°, 90°, 180°, 270° or 0,
100, 200, 300 gon).
Beep is disabled.Off
Screen 2/4
Field Description
Tilt On Tilt sensor is enabled for X and Y axis.
Off Tilt sensor is disabled.
X Only Tilt sensor is enabled for X axis only.
Hz Increment Right Set measurement of horizontal angle to clockwise
direction.
Left Set measurement of horizontal angle to anticlockwise
direction.
Access
General settings
Settings 31
