Field Description
ft-in1/8 US feet-inch-1/8 inch [ft].
Dist. Decimal Sets the number of decimal places shown for all distance fields. This set-
ting is for data display and does not apply to data export or storage.
3 Distance with three decimals.
4 Distance with four decimals.
Screen 3/4
Field Description
Temp. Unit Sets the units shown for all temperature fields.
°C Degree Celsius.
°F Degree Fahrenheit.
Press. Unit Sets the units shown for all pressure fields.
hPA Hecto Pascal.
mmHG Millimeter mercury.
inHg Inch mercury.
Code Defines whether the code is used for one or for many measurements.
Rec/Reset The code is cleared after saving a measurement with
softkey ALL or REC.
Permanent The code is kept for all further measurements until it is
deleted manually or until another code is selected.
Auto-Off 30min The instrument switches off after 30 minutes without
any activity
Off Automatic switch-off is deactivated.
☞
Battery discharges quicker.
Port RS232C Communication is via the serial interface.
Bluetooth Communication is via Bluetooth.
Baudrate 9600, 19200,
115200
Sets the baudrate for the serial interface.
Coord. type NEZ/ENZ Sets the coordinate type.
Screen 4/4
Field Description
Language Sets the software interface to the preferred language. Available languages:
•
English
•
Korean
•
French
•
Italian
•
Turkish
•
Spanish
5.2 EDM Settings
The settings on this screen define the active EDM, Electronic Distance Measurement. Different
settings for measurements are available with Reflectorless (NP) and Prism (P) EDM modes.
1. Select Setting from the Main Menu.
2. Select EDM Setting from the Setting menu.
Description
Access
Settings 33
