Back To go back without saving the
entered job data.
OK To save the entered job data and
return to the pre-settings screen.
The new job is set as current job.
Once a job is set up, all subsequent recorded data will be stored in this job.
If no job was defined and an application was started and a measurement was recorded, then the
system automatically creates a new job and names it "DEFAULT".
8.4 Selecting the Station
All measurements and coordinate computations are referenced to the set station coordinates.
The coordinates can be entered manually or selected from the memory.
The station coordinates that are set must include:
•
at least grid coordinates (E, N), and
•
the station height, if required.
Directions
X Easting
Y Northing
Z Height
Station coordinates
Stn.X Easting coordinate of station
Stn.Y Northing coordinate of station
1. Select Program (2) from the Main Menu.
2. To select an application in the Program menu, press a function key, F1 - F4.
3. Select Set STA (2) in the pre-settings screen of the application.
Set the station coordinates
Find To search for an existing point
with the entered point ID.
List To select a point from the list of
existing points.
Coord. To enter the point coordinates
manually.
Recorded data
Description
Access
Set station
Applications - Getting Started 47
