Meas. To measure the known point.
Result To calculate and display the
result.
Step-by-Step
1. Set the two known points.
2. To calculate and display the Inverse result, press Result.
3. To save the result, press REC.
9.8.3 COGO Calculation - Traverse Method
1. Select Traverse&Inverse (1) from the COGO menu.
2. Select Traverse (2).
Use the Traverse subapplication to calculate the position of a new point using the bearing and
the distance from a known point. Offset optional.
Known
P1 Known point
a
Direction from P1 to P2
d1 Distance between P1 and P2
d2 Positive offset to the right
d3 Negative offset to the left
Unknown
P2 COGO point without offset
P3 COGO point with positive offset
P4 COGO point with negative offset
Meas. To measure the known point.
Result To calculate and display the
result.
Inverse
Access
Description
Traverse
Application 63
