Reflectorless Range
*
:
350 m
Accuracy: 3 mm + 2 ppm
Measuring time: 1.5 s
*
Calculated by Kodak Gray Card white side (90% reflective), exact distance depends on meas-
uring object, observation and environment conditions.
14.5 Conformity to National Regulations
•
FCC Part 15, 22 and 24 (applicable in US)
•
Hereby, GeoMax AG declares that the radio equipment type Zoom10 is in compliance
with Directive 2014/53/EU and other applicable European Directives.
The full text of the EU declaration of conformity is available at the following Internet
address: http://www.geomax-positioning.com/Downloads.htm.
Class 1 equipment according to European Directive 2014/53/EU (RED) can be
placed on the market and be put into service without restrictions in any EEA
member state.
•
The conformity for countries with other national regulations not covered by the FCC part
15, 22 and 24 or European Directive 2014/53/EU has to be approved prior to use and
operation.
Type Frequency band [MHz]
Bluetooth 2402 - 2480
Type Output power [mW]
Bluetooth 2.5
14.6 Scale Correction
By entering a scale correction, reductions proportional to distance can be taken into account.
•
Atmospheric correction.
•
Reduction to mean sea level.
•
Projection distortion.
The slope distance displayed is correct if the scale correction in ppm, mm/km, which has been
entered corresponds to the atmospheric conditions prevailing at the time of the measurement.
The atmospheric correction includes:
•
Adjustments for air pressure
•
Air temperature
For highest precision distance measurements, the atmospheric correction should be determined
with:
•
An accuracy of 1 ppm
•
Air temperature to 1 °C
•
Air pressure to 3 mbar
Atmospheric corrections in ppm with temperature [°C], air pressure [mb] and height [m] at
60 % relative humidity.
Conformity to national
regulations
Frequency band
Output power
Use of scale correction
Atmospheric correction
Atmospheric corrections
°C
Technical Data 97
